14GN,(8 1/2 x 20 + Black,Dovetail with 5 Fold-up
VIN: 010276
Call for Quote
(803) 438-7317Lugoff, SC
For those who pour blood, sweat, and tears into their work every day of the week, the low-profile 14GN Single Wheel Tandem Axle Gooseneck Trailer is here to make your job a little easier. A medium-duty, single-wheel gooseneck trailer thats built for strength and durability, the 14GN delivers reliable performance for a wide range of needs for contractors, farmers, and equipment haulers. From its LED lights, treated floor, dual jacks, and adjustable coupler, this is a professional-grade trailer thats outfitted with the features that hardworking individuals demand to get the job done.
- Overview
- Features/Specifications
- Standard/Optional Equipment
- Financing
Overview
14GN,(8 1/2 x 20 + Black,Dovetail with 5 Fold-up
Big Tex 14GN Single Wheel Tandem Gooseneck
The 14GN is our medium duty single wheel gooseneck. This model combines many of the Big Tex unique features including low profile decks, LED lights, treated floor, dual jacks, and adjustable coupler.
Structural Details:
•12'' I-Beam Frame & Neck
•3'' Channel Crossmembers-Plasma Pierced Through Frame
•2 Side Bed Steps & Handles
•1-1/4'' Pipe Chain Spool Between Stake Pockets
•Heavy Duty Rub Rail w/ Stake Pockets on 24'' Centers
•3-Year Structural Warranty
•5' Self Cleaning Dovetail w/ Variety of Ramp Options
•Dual Fold Over Ramps-Standard Equipped
Where the Rubber Meets the Road:
•Premium Dexter EZ Lube Cambered 7,000# Axles
•ST 235/80 R-16 Load Range E Dual Radial Tires
•NEV-R-ADJUST Electric Brakes
•Complete Break-A-Way System w/Battery & Charger
•Spare Tire and Wheel
More Standard Features:
•Lockable Toolbox Between GN Uprights
•Ball Adjustable Pipe Coupler
•Dual 12K Drop Leg Jacks w/ Greasable Handle (Bolted On)
•Sealed Modular Wiring Harness
•All Grommet Mount Sealed LED Lighting and Reflective Conspicuity Tape
•Spare Tire Mount
•2'' Treated Pine Or Douglas Fir Floor
•3/8'' Grd. 70 Safety Chains w/Safety Latch Hook (2 each)
•Automotive Grade, Highly Decorative and Protective Finish
Lengths Available:
•20’+5’
•22’+5’
•25’+5’
•28’+5’
Optional Add-Ons
•Electric Over Hydraulic Brakes
•Deck on Neck (Removable)
•Sliding Winch Track and Winches
•Underbody Tool Box(s)
•Additional Rear Ramps Available
•Mega Ramps
•Center Pop-Up
*Additional options may be available, contact store for details.
*Photo used for illustrative purposes and may not be an exact representation of actual trailer on lot.
- Availability:
- In Stock
- Axle Config:
- Tandem
- Max Payload:
- 11120 lbs.
- External Width:
- 102"
- External Length:
- 20+5
- Weight:
- 4780
- Hitch Type:
- Gooseneck
- Category:
- Gooseneck/Pintle Trailers
- Year:
- 2017
- Condition:
- New
- Material:
- Steel
- Open/Enclosed:
- Open
- Warranty:
- Factory Warranty Included
- Color:
- Black
- GVWR:
- 15900
- Capacity:
- 11120
Features/Specifications
Features
| Axle | (2) 7,000# Quick Lubricating w/Electric Brakes |
|---|---|
| Jack | Dual 12,000# Drop Leg Side Wind (Bolted On) |
| Neck | 12" I-Beam, 14# |
| Tire | ST235/80 R-16 Load Range E |
| Floor | 2" Treated Pine or Douglas Fir* |
| Frame | 12" I-Beam, 14# |
| Wheel | 16" x 6"; Black Mod 8 Bolt |
| Finish | Superior Quality Finish is Applied for a Highly Decorative and Protective Finish. |
| Lights | L.E.D. D.O.T. Stop, Tail, Turn & Clearance |
| Coupler | 2-5/16" Ball Adjustable Pipe |
| Dovetail | 5 Cleated Dovetail w/5 Double Hinged, Spring-Assisted Flip-Over Ramps |
|---|---|
| G.V.W.R. | 15,900# |
| Elec. Plug | 7-Way RV |
| Hitch Type | Gooseneck |
| Side Rails | 5" Channel w/Rub Rail, Stake Pockets, and Chain Spools |
| Suspension | Multi-Leaf Slipper Spring w/Equalizer |
| Crossmembers | 3" Channel |
| Finish (Prep) | Steel is Cleaned to Ensure a Professional Smooth Finish. |
| Safety Chains | 3/8" Grd. 70 w/Safety Latch Hook (2 each) |
| G.A.W.R. (Ea. Axle) | 7,000# |
Specifications
Big Tex 14GN Single Wheel Tandem Axle Gooseneck Trailer
| Model | Description |
|---|---|
| 14GN-20+5 | 102" x 20' + 5' Single Wheel Tandem Axle Gooseneck |
| 14GN-22+5 | 102" x 22' + 5' Single Wheel Tandem Axle Gooseneck |
| 14GN-25+5 | 102" x 25' + 5' Single Wheel Tandem Axle Gooseneck |
| 14GN-28+5 | 102" x 28' + 5' Single Wheel Tandem Axle Gooseneck |
| 14GN-30+5 |
Dimensions
| Length | A | B | C |
|---|---|---|---|
| 20'+5' | 240" | 186" | 54" |
| 22'+5' | 264" | 210" | 54" |
| 25'+5' | 300" | 240" | 60" |
| 28'+5' | 336" | 264" | 72" |
Trailer Weights & Capacities
| Length | Empty Weight | Payload | Box Capacity |
|---|---|---|---|
| 20'+5' | 4,780# | 11,120# | N/A |
| 22'+5' | 4,980# | 10,920# | N/A |
| 25'+5' | 5,280# | 10,620# | N/A |
| 28'+5' | 5,580# | 10,320# | N/A |
| 0# | 15,900# | N/A |
Standard/Optional Equipment
Standard Equipment
- 2-5/16" Ball Adjustable Pipe Coupler
- Dual 12,000# Drop Leg Jacks (Bolted on) w/Greasable Handle
- 102" Overall Width
- Low Profile Bed, Pierced- Beam Frame
- Lockable Toolbox Between GN Uprights
- (2) Side Bed Steps & Handles
- 3/8" Heavy Duty Rub Rail
- Stake Pockets Along Sides, 24" On Center
- 1-1/4" Pipe Chain Spools Between Stake Pockets
- Quick Lubricating Hubs
- Premium Brand Axles
- Forward Self Adjusting Electric Brakes on All Hubs
- Cambered Axles
- Grommet Mount Sealed Lighting
- L.E.D. Lighting Package
- Sealed, Modular Wiring Harness
- 5 Dovetail w/ 5 Double Hinged Spring Assist Flip-Over Ramps
- Complete Break-A-Way System w/Charger
- Spare Tire Mount (Top of Neck)
- Radial Tires
- Zip Breakaway Cable
- Spare Tire & Wheel - Standard Equiped
Optional Equipment
| Category | Description |
|---|---|
| BODY | Blackwood Pro Rubber Infused Floor |
| BODY | Removable Deck on the Neck- Bolt On (8 W x 6 L) |
| BRAKES | Electric Over Hydraulic Brakes (Drum) |
| CARGO CONTROL | 4" Sliding Winch |
| CARGO CONTROL | 4" Weld-On Winch |
| CARGO CONTROL | 4" x 30 Strap |
| CARGO CONTROL | 5/8" D-Ring |
| CARGO CONTROL | Low Profile Tool Box 15" x 15" x 36" (Side Mount) |
| CARGO CONTROL | Sliding Winch Track (Per 6 Section) |
| JACK | Dual 2-Speed Landing Gear |
| JACKS | Dual Electric Over Hydraulic Jacks by Stillwell |
| RAMPS | (2) 5 MEGA Ramps |
| RAMPS | 8 Rear Slide-In Ramps (Straight Deck Only) |
| RAMPS | No Dovetail Option (Deletes Dovetail and Ramps) |
| TIRE/WHEEL | Tire and Spare Upgrade (ST235/85 R-16 LR-G) |
